Wednesday, January 23, 2008

How to Transfer Fixed Sized Data With Async Sockets

This post was inspired by the discussion in MDSN forums.

Discussion on that forum showed that there is misunderstanding of the principles of data transfer across the network, especially in asynchronous way.

I wrote simple client/server application that demonstrates usage of asynchronous sockets to transfer fixed sized data from client to server.

Usually data exchange between server and client is done in some special way (or special order). Such an order is called communication protocol.
More information on network and communication protocols can be found here and here

The sample here also uses communication protocol. It is very simple, client prefixes the data with 4 bytes that hold data size. Format of the data that will go to the wire can be shown like this [4 bytes - data size][data - data size].

Here comes implementation with short comments. Asynchronous communication via sockets involves methods like BeginReceive/EndReceive - for data receiving and BeginSend/EndSend for sending. The sample demonstrates only how async sockets work and the fact that data is received in the stream like way.
More information about network programming can be found here


At first we define the state that will be passed between async calls. State is defined as following:

/// Server state holds current state of the client socket

class ServerState
public byte[] Buffer = new byte[512]; //buffer for network i/o
public int DataSize = 0; //data size to be received by the server
public bool DataSizeReceived = false; //whether prefix was received
public MemoryStream Data = new MemoryStream(); //place where data is stored
public Socket Client; //client socket

Server is listening for the clients using Socket.Accept method.
Here is the server listening loop:

//server listening loop
while (true)
Socket client = serverSocket.Accept();
ServerState state = new ServerState();

state.Client = client;
//issue first receive
client.BeginReceive(state.Buffer, 0, state.Buffer.Length, SocketFlags.None,
new AsyncCallback(ServerReadCallback), state);

When data comes to the client socket ServerReadCallback is called. There server can read received data and process it.

Here is the implementation of that method:

private void ServerReadCallback(IAsyncResult
ServerState state = (ServerState)ar.AsyncState;
Socket client = state.Client;
SocketError socketError;

int dataRead = client.EndReceive(ar, out socketError);
int dataOffset = 0; //to simplify logic

if (socketError != SocketError.Success)

if (dataRead <= 0)
{ //connection reset

if (!state.DataSizeReceived)
if (dataRead >= 4)
{ //we received data size prefix
state.DataSize = BitConverter.ToInt32(state.Buffer, 0);
state.DataSizeReceived = true;
dataRead -= 4;
dataOffset += 4;

if ((state.Data.Length + dataRead) == state.DataSize)
{ //we have all the data
state.Data.Write(state.Buffer, dataOffset, dataRead);

Console.WriteLine("Data received. Size: {0}", state.DataSize);

{ //there is still data pending, store what we've
//received and issue another BeginReceive
state.Data.Write(state.Buffer, dataOffset, dataRead);

client.BeginReceive(state.Buffer, 0, state.Buffer.Length,
SocketFlags.None, new AsyncCallback(ServerReadCallback), state);

As you can see server implementation is very simple. It receives data size prefix at first and if it is complete (first 4 bytes are received) then proceeds with data receive.

It is very important to always check the number of received bytes. This number can vary.


Client implementation is pretty straightforward. It also has a state that is passed along async operations.

public class ClientState
public Socket Client; //client socket
public byte[] DataToSend; //data to be trasferred
public int DataSent = 0; //data already sent

The data being sent is prefixed with its size.

ClientState state = new ClientState();
state.Client = socket;

//add prefix to data
state.DataToSend = new byte[data.Length + 4];
byte[] prefix = BitConverter.GetBytes(data.Length);
//copy data size prefix
Buffer.BlockCopy(prefix, 0, state.DataToSend, 0, prefix.Length);
//copy the data
Buffer.BlockCopy(data, 0, state.DataToSend, prefix.Length, data.Length);

socket.BeginSend(state.DataToSend, 0, state.DataToSend.Length,
SocketFlags.None, new AsyncCallback(ClientSendCallback), state);

And finally the implementation of ClientSendCallback

private void ClientSendCallback(IAsyncResult ar)
ClientState state = (ClientState)ar.AsyncState;
SocketError socketError;
int sentData = state.Client.EndSend(ar, out socketError);

if ( socketError != SocketError.Success )

state.DataSent += sentData;

if (state.DataSent != state.DataToSend.Length)
{ //not all data was sent
state.Client.BeginSend(state.DataToSend, state.DataSent,
state.DataToSend.Length - state.DataSent, SocketFlags.None,
new AsyncCallback(ClientSendCallback), state);
{ //all data was sent
Console.WriteLine("All data was sent. Size: {0}",

As you can see implementation details are very simple.
There are several important things here:
  • Data is received in pieces, you can't predict how much data you will receive during one method call
  • When using async sockets always pass the same state object in the context of the same client

The code sample above illustrates the idea of tranferring size-prefixed data between client and server in the async way. Please, note that only one message per connection is passed from client to server. To add multiple message handling - server code has to be modified according to your custom the protocol.

Saturday, January 19, 2008

Unmanaged Debugging Option Very Useful in Visual Studio .NET

When developing managed code that is interacting with unmanaged world one has to be very careful, especially when working with unmanaged memory.

Here's an example how critical memory bug can be omitted.

I was developing code that used Marshal.AllocHGlobal method to allocate unmanaged memory. Naturally I was freeing that memory after usage.

The code looked like
IntPtr unmanagedMemory = IntPtr.Zero;
unmanagedMemory = Marshal.AllocaHGlobal(nBytes);
//invoking unmanaged method here via P/Invoke

Everything was okay; application was working perfectly, except occasional crashes with AccessViolationException. Exception of this type can happen when something is writing into wrong memory offset and system reacts by throwing an exception.

Exception wasn't thrown every time application was running and it was hard to detect what was causing it. At the top of callstack was ntdll.dll module.

I decided to turn on unmanaged debugging and see what is happening under the hood in the unmanaged world.
(To turn unmanaged debugging in Visual Studio you need to go to Project Properties -> Debug -> Check "enable unmanaged code debugging").

After turning on unmanaged debugging I've got an exception immediately.

Marshal.FreeHGlobal(unmanagedMemory) was throwing exception saying that there was heap corruption. This exception was repeating constantly.

Finally, the bug was found - unmanaged function was not behaving well with the pointer passed to it.

Every time you're developing managed code that is interacting with unmanaged memory it is highly desirable to turn on unmanaged debugging. This will save a lot of time when tracking memory related issues and exceptions. Also a lot of information about debugging .NET applications can be found in .NET Debugging
